12w led recessed ceiling spot light

SPECIFICATIONS

Model		1003YF12A	1003YK12A	1003YF12B	1003YK12B
Des		Basic Type	Basic Type	Pin Hole	Oval Hole
Electronical	Input Voltage：	220-240VAC
	Frequency：	50Hz/60Hz
	System Power：	12W
	Power Factor：	>0.5
	Driver Brand	Philips/Tridonic/Lifud
	Output	DC30-42VAC 300mA
Lumination	LED Chip Model	Cree, Bridgelux
	CRI	》90， 95， 97
	System Lumen	850lms	840lms	780lms	800lms
	Efficiency of Fixture	60-70lm/w
	Color Temperature：	2700K, 3000K, 3500K, 4000K，6000K
Optical	Beam Angle	15° 24° 36° 55°
	Secondary Reflector	white, black, golden, pearl black, silver
	Filter optional	Honey comb
Structure	Housing Material：	Diecase Aluminum
	Dimension	Ø86x107mm
	Cut hole	Ø75mm
	IP grade	IP20
	Tiltable	Fixed	Adjustable	Fixed	Adjustable
Control method	Dimmable	On/Off, Triac/0-10V/Dali
